LCD Parameters
| NO. | ITEM | SPECIFICATIONS |
| 1 | Product Name | 1.28-inch Round ShaCircle TFT LCD Display |
| 2 | Display Mode | Normal black |
| 3 | Viewing Direction | All |
| 4 | Resolution | 128x128 dots |
| 5 | Operating Temperature | -20~+70℃ |
| 6 | Storage Temperature | -30~+80℃ |
| 7 | FPC Connector | 25 pins, ZIF type |
| 8 | Panel Type | IPS |
| 9 | Interface | SPI |
| 10 | Backlight Type | 3LEDs, White |
| 11 | Brightness | 250 cd/m2 |
| 12 | Outline Dimension | 25.24(W)* 27.14(H)* 1.95(T) mm |
| 13 | Active Area | 23.03(W)* 23.03(H) mm |
TFT Screens ( 0.96 inch~10.1 inch )
we mainly develop small-middle sizes TFT LCD screens, including 0.9", 0.96", 1.06", 1.14", 1.28", 1.3", 1.44", 1.54", 1.69", 1.77", 1.83", 1.99", 2.0", 2.2", 2.4", 2.8", 2.95", 3.13", 3.2", 3.5", 3.97", 4.3", 5", 5.5", 7", 8" and 10.1", etc.
Please let me know your requirements, we will suggest some models for your optional.
Also, we can customize the FPC, Interface, Touch Panel, Cover Glass, and Backlight based on your demands.
TFT LCD (Thin-Film Transistor Liquid Crystal Display) is a type of LCD that uses thin-film transistor (TFT) technology to improve image quality. It is commonly found in televisions, computer monitors, smartphones, and other display devices.
Key Features of TFT LCDs:
-
Active Matrix Technology: Each pixel is controlled by a small transistor, allowing faster response times and better image quality.
-
High Resolution & Color Accuracy: TFT LCDs can display vibrant colors and sharp images.
-
Backlit Display: Requires a light source, typically LED backlighting, since LCDs don’t emit light themselves.
-
Good Contrast & Brightness: Improved over traditional passive matrix LCDs.
-
Power Consumption: Generally higher than e-ink or OLED but efficient with LED backlighting.
Possible Uses:
-
Wearable devices
-
Small graphical interfaces
-
Sensor data visualization
-
DIY electronics projects (Arduino, Raspberry Pi)
FAQ
1. Q: Where is your factory?
A. Our office is in Shenzhen, Guangdong, and our factory is located in Jiangxi Province.
2. Q: Will you offer a free sample?
A: For the first cooperation, samples will be charged, and the amount will be returned at the mass order stage.
In regular cooperation, samples can be free.
3. Q: What is the delivery time?
A: For sample order: 2-3 weeks. For mass production: 4-6 weeks.
4. Q: Can you customize the LCD or touch screen for me?
A: Yes, we can provide custom services.
Regarding TFT LCD, interface, FPC cable, Backlight, Cover glass, and Touch Panels can be customized. 5. Q: How do you control the quality of products?
A: All products are 100% inspected before shipment.
